Senke YPC-AD 27 Inch Andon Buzzer Industrial All-in-one PC, High Brightness Workshop Kanban Station Touch Panel
SK-AD
Fanless sealed housing, built-in Andon alarm buzzer, 27-inch high brightness screen, dual LAN, multi serial ports, embedded installation
Senke YPC-AD270H 27 inch Andon buzzer industrial all-in-one PC with built-in fault alarm buzzer, high brightness anti-glare screen, fanless sealed design, specially designed for workshop Andon kanban, assembly line station monitoring and MES production data display.
YPC-AD Series Overview
Pre-order Features: 27-inch large-size high-brightness screen, built-in Andon buzzer alarm module, fanless integrated enclosure, dedicated for production line Andon kanban & station industrial control terminals [Introduction] Efficient fin passive heat dissipation, full hardware customization, shockproof and anti-electromagnetic interference, clear high-bright display under factory strong light, stable long-cycle operation for workshop Andon management system. [System] Intel Celeron / 7th/10th/12th Gen Core i3/i5/i7 optional. [Heat Dissipation] Integrated cast aluminum housing, thickened rear fin cooling structure, no fan maintenance-free design. [Environment] Dust-proof, splash-proof and oil-proof casing, continuous stable operation in -20℃~65℃ workshop environment. [Interfaces] Dual Gigabit Ethernet, RS485 serial port, built-in Andon buzzer interface, Phoenix terminal, multiple USB expansion ports, supporting signal linkage with production line Andon system.
YPC-AD270H
Basic Specifications
| Item | Standard Configuration |
|---|---|
| Model | YPC-AD270H |
| Display | 27" Wide Industrial LCD Screen |
| Touch Screen | Capacitive / Resistive touch optional |
| Resolution | 1920*1080 |
| Brightness | 350cd/㎡ high brightness, anti-glare surface |
| Built-in Module | Integrated Andon alarm buzzer, fault signal prompt |
| Processor | Intel® Celeron / 7th/10th/12th Gen Core i3/i5/i7 |
| BIOS | AMI UEFI BIOS |
| Chipset | Intel® SOC |
| Graphics | Integrated Intel HD/UHD/Iris Xe Graphics |
| Network | 2*RTL8111H Gigabit Ethernet, support WoL |
| Serial Port | Isolated RS485 for Andon system signal transmission |
| Expansion Port | Phoenix terminal, multi USB ports, buzzer signal output port |
| Cooling | Fanless fin-type passive heat dissipation |
| Enclosure | Cast aluminum dustproof fully sealed housing |
| Operating Temperature | -20℃ ~ 65℃ |
| Memory | 4GB~32GB DDR configurable |
| Storage | 128GB~1TB SSD configurable |
| Supported OS | Windows / Linux / Android |
| Application | Production Andon kanban, workshop station monitoring, assembly line fault alarm, MES production display |
| Installation Ways | Embedded, wall-mounted, vertical bracket installation for workshop station cabinet |
Senke Electronic is a manufacture of industrial panel pc, industrial box pc, rugged tablet, kiosk payment and digital display advertising.
